DX-1100

第9/8代Intel? Xeon?和Core?處理器，優越性能，緊湊型和模塊化的強固型工作站

產品特點

支持第9/8代Intel? Xeon?和Core? 8-core處理器
三重獨立顯示，具有4K / 2K UHD分辨率（HDMI / DP / DVI-I）
2個2.5” SATA HDD / SSD熱插拔抽取式托盤，3個mSATA插槽
2個USB 3.1（10Gb/s），可實現高速數據傳輸
1個M.2 E Key插槽（CNVi），3個全尺寸Mini-PCIe插槽，1個SIM卡插槽
支持I / O擴展的CMI接口
支持POE +和智能點火控制（帶可選配的CFM模塊）
寬工作溫度 -40°C 至 70°C
E-Mark, LVD EN62368-1, EN50121-3-2

產品介紹
詳細規格

產品介紹

德承DX-1100是一款堅固耐用的工作站，專為滿足高性能計算平臺的需求而設計?；贗ntel? 工作站等級C246芯片組，支持第9/8代Intel? Xeon / Core處理器（Coffee Lake R/S），支持多達8個處理內核以及高效顯卡，可支持12*RJ45（獨立千兆網口），支持8*USB（2*USB 3.1/6*USB 3.0），可滿足8*POE或者8*M12（航空插頭）的特殊應用。

尺寸大小僅為3.2升，適合緊湊的空間和高性能的需求，盡管尺寸非常緊湊，但DX-1100仍然提供靈活性的模塊化I/O擴展，提供雙熱插拔2.5英寸HDD/SSD托盤，并具有RAID功能。得益于Cincoze的CFM技術（控制功能模塊）, DX-1100可即時配置網口供電（POE）和智能點火控制功能，可應用于廣泛的工業現場，例如：機器視覺、智能交通、自動化等領域。產品通過SGS國際認證機構獲得CE、FCC、EN-50121-3-2、EN-60950-1、E-mark等專業認證。

詳細規格

Model Name		DX-1100
System	Processor	? 9th Generation Intel? Coffee Lake-R S Series CPU: - Intel? Xeon? E-2278GEL 8 Cores Up to 3.9 GHz, TDP 35W - Intel? Core? i7-9700E 8 Cores Up to 4.4 GHz, TDP 65W - Intel? Core? i5-9500E 6 Cores Up to 4.2 GHz, TDP 65W - Intel? Core? i3-9100E 4 Cores Up to 3.7 GHz, TDP 65W - Intel? Core? i7-9700TE 8 Cores Up to 3.8 GHz, TDP 35W - Intel? Core? i5-9500TE 6 Cores Up to 3.6 GHz, TDP 35W - Intel? Core? i3-9100TE 4 Cores Up to 3.2 GHz, TDP 35W ? 8th Generation Intel? Coffee Lake S Series CPU: - Intel? Xeon? E-2176G 6 Cores Up to 4.7 GHz - 12M Cache, TDP 80W - Intel? Xeon? E-2124G 4 Cores Up to 4.5 GHz - 8M Cache, TDP 71W - Intel? Core? i7-8700 6 Cores Up to 4.6 GHz - 12M Cache, TDP 65W - Intel? Core? i5-8500 6 Cores Up to 4.1 GHz - 9M Cache, TDP 65W - Intel? Core? i3-8100 4 Cores 3.6 GHz - 6M Cache, TDP 65W - Intel? Core? i7-8700T 6 Cores Up to 4.0 GHz - 12M Cache, TDP 35W - Intel? Core? i5-8500T 6 Cores Up to 3.5 GHz - 9M Cache, TDP 35W - Intel? Core? i3-8100T 4 Cores 3.1 GHz - 6M Cache, TDP 35W - Intel? Pentium? G5400 2 Cores 3.7 GHz - 4M Cache, TDP 58W - Intel? Pentium? G5400T 2 Cores 3.1 GHz - 4M Cache, TDP 35W - Intel? Celeron? G4900 2 Cores 3.1 GHz - 2M Cache, TDP 54W - Intel? Celeron? G4900T 2 Cores 2.9 GHz - 2M Cache, TDP 35W
	Chipset	Intel C246
	Memory	? 2x DDR4-2666/2400 MHz SO-DIMM Sockets ? Support up to 64 GB (Un-buffered and Non-ECC type) * i3/Pentium/Celeron: DDR4 2400 MHz
	Graphics	? Integrated Intel? UHD Graphics (Xeon: UHD P630; i7/i5/i3: UHD 630; Pentium/Celeron: UHD 610) ? Supports Triple Independent Display (DVI-I/DisplayPort/HDMI)
	Audio	Realtek? ALC888, High Definition Audio
	BIOS	AMI 32 MB BIOS
I/O Interface	DVI	1x DVI-I Connector (VGA: 1920 x1080 @ 60 Hz; DVI-D: 1920 x1200 @ 60 Hz)
	DP	1x DisplayPort Connector (3840 x 2160 @30Hz)
	HDMI	1x HDMI Connector (3840 x 2160 @30Hz)
	LAN	2x GbE LAN (Support WoL, Teaming, Jumbo Frame, IEEE 1588v2 and PXE), RJ45 - GbE1: Intel? I219-LM - GbE2: Intel? I210-IT Optional Module ．4x 10/100/1000 Mbps, RJ45 Port ．4x 10/100/1000 Mbps, M12 Port
	PoE+	Optional Module ．4x PoE+, Individual port 25.5W (with CMI-LAN01, RJ45 Port) ．4x PoE+, Individual port 25.5W, (with CMI-M12LAN01, M12 Port)
	Serial Port	4x RS-232/422/485 with Auto Flow Control Support 5V/12V, DB9 Optional Module ．2x RS-232/422/485, DB9 Connector
	USB	2x USB 3.1 (Type-A) 6x USB 3.0 (Type-A)
	Optical Isolated DIO	Optional Module ．16x Optical Isolated DIO(8DI, 8DO), 20 pin Terminal Block
	Line-Out	1x Line-Out, Phone Jack 3.5mm
	Mic-In	1x Mic-In, Phone Jack 3.5mm
	Power Button	1x ATX Power On/Off Button
	AT/ATX Switch	1x AT/ATX Mode Switch
	Rest Button	1x Rest Button
	Clear CMOS Switch	1x Clear CMOS Switch
	Remote Power On/Off Connector	1x Remote Power On/Off Connector, 2-pin Terminal Block
	External FAN Connector	1x External FAN Connector, 4-pin Terminal Block (support smart fan by BIOS)
Storage	SSD/HDD	2x 2.5" Front Accessable SATA HDD/SSD Bay (SATA 3.0)
	mSATA	3x mSATA Socket (SATA 3.0, shared by Mini-PCIe socket)
	RAID	Supports S/W RAID 0, 1, 5 & 10
Expansion	PCI/ PCIe	-
	CFM (Control Function Module) Interface	1x CFM Interface for CFM Modules
	CMI (Combine Multiple I/O) Interface	3x CMI Interface for CMI Modules
	Mini PCI Express	3x Full-size Mini-PCIe Sockets
	M.2 Socket	1x M.2 2230 Socket (Key E)
	SIM Socket	1x SIM Socket
	Antenna Holes	3x Antenna Holes
Other	Instant Reboot	Support 0.2sec
	Power Ignition Sensing	Optional Module ．CFM with Delay Time Management and Selectable 12V/24V, Dip Switch
	Super Cap	SuperCap Integrated for CMOS Battery Maintenance-free Operation
	Watchdog Timer	Software Programmable Supports 256 Levels System Reset
Power Requirement	Power Type	AT/ATX
	Power Input Voltage	9~48VDC
	Connector	3-pin Terminal Block
	Power Adapter	Optional AC/DC Adapter ．AC/DC 24V/5A, 120W ．AC/DC 24V/9.2A, 220W
Physical	Dimension (WxDxH)	242 x 174 x 77 mm
	Weight Information	3.6 kg
	Mechanical Construction	Extruded Aluminum with Heavy Duty Metal
	Mounting	Wall / VESA / DIN Rail / Side
	Unibody Design	Yes
	Fanless Design	Yes
	Jumper-less Design	Yes
	Cable-less Design	Yes
Protection	Reverse Power Input Protection	Yes
	Over Voltage Protection	Protection Range: 51~58V Protection Type: shut down operating voltage, re-power on at the preset level to recover
	Over Current Protection	15A
	ESD Protection	+/-8kV (air), +/-4kV (contact)
	Surge Protection	3.84 kV (impedance 12 ohm 1.2/50us waveform)
Operating System	Windows	Windows? 10
Operating System	Linux	Support by project
Environment	Operating Temperature	35W TDP Processor: -40°C to 70°C 54~65W TDP Processor: -40°C to 45°C 71~80W TDP Processor: -40°C to 40°C * PassMark BurnInTest: 100% CPU, 2D/3D Graphics (without thermal throttling) * With extended temperature peripherals; Ambient with air flow * According to IEC60068-2-1, IEC60068-2-2, IEC60068-2-14
	Storage Temperature	-40°C to 85°C
	Relative Humidity	95% RH @ 40°C (Non-condensing)
	Shock	Operating, 50 Grms, Half-sine 11 ms Duration * w/ SSD, according to IEC60068-2-27
	Vibration	Operating, 5 Grms, 5-500 Hz, 3 Axes * w/ SSD, according to IEC60068-2-64
	EMC	CE, FCC Class A, EN50121-3-2, E-Mark (E13 No.10R-0515210)
	Safety	LVD EN62368-1
	MTBF	407,391 Hours - Database: Telcordia SR-332 Issue3, Method 1, Case 3
